Description
Compact touch B-scan with optional Biometry and Pachymetry has been designed to provide a new standard in the world of compact and portable ophthalmic ultrasound system. The unparalleled quality of the QUANTEL MEDICAL B-Scan allows better visualization of details, improving your ability to differentiate structures and pathologies. The Biometry Option with Compact Touch has been designed to provide the precision you and your patients need for premium and accommodating IOL’s and calculation in post-refractive eyes. The pachymetry option is essential in glaucoma and surgery assessment.
- Compact Touch 3 in 1 Ultrasound System
- Quantel Medical, Inc.
- Get quote
- The performance in a compact system: no PC required, colour and touch screen, only 9.4 lbs (4.2 kg), easy data transfer to EMR/network, 2 USB + 2 PS2 +1 ethernet port.
- B-Scan: automatic recording with Cineloop, adjustable gain on frozen pictures, post processing tools, user friendly software with unlimited data base.
- Biometry option: 6 IOL formulas, 6 post-refractive formulas, scleral echo discrimination to eliminate optic nerve scans, a specific and customizable mode for patients with silicon in vitreous.
- Pachymetry option: multiple corneal maps with graphical displays, adjustable corneal velocity, 4 measuring modes.
- Biometry in B mode: Especially useful on patients with high myopia, or posterior staphyloma. The cross vector is positioned along the visual axis of a B-Scan image. The axial length is automatically measured and transferred into biometry software for immediate IOL calculation.
- ProBeam option: Biometry probe with built-in laser pointer, projects a luminous fixation point on the wall or ceiling. When focusing on this point with the opposite eye, the A-Scan beam is automatically focused on the patient’s visual axis for even faster scans.
- US FDA
- B scan with A scan and pachymetry in option
- Weight: 9.44 lbs (4.2 kg)
Height: 10.63" (27 cm)
Width: 14.76" (37.5 cm)
Depth: 3.94" (16 cm) - B probe: 10 MHz, A probe: 11 MHz, Pachymetry probe: 20 MHz
- Colour and touch screen
- 256
- Zoom (from 50 to 500 %), gain, cineloop and post-processing tools.
- Database inside and/or download to an external memory or server (EMR)
